HDPE Monofilament Rope
Specifications
| SIZE (DIAMETER) | WEIGHT | MINIMUM BREAKING STRENGTH | |||
|---|---|---|---|---|---|
| mm | Inch | Lbs/100 ft | Kgs/100 mts | Kgs | Lbs |
| 4 | 5/32″ | 0.54 | 0.81 | 200 | 441 |
| 6 | 1/4″ | 1.22 | 1.82 | 400 | 882 |
| 8 | 5/16″ | 2.20 | 3.27 | 700 | 1543 |
| 10 | 3/8″ | 3.29 | 4.90 | 1100 | 2425 |
| 12 | 1/2″ | 4.84 | 7.20 | 1500 | 3307 |
| 14 | 9/16″ | 6.38 | 9.50 | 2100 | 4630 |
| 16 | 5/8″ | 8.60 | 12.80 | 2800 | 6173 |
| 18 | 3/4″ | 10.82 | 16.10 | 3500 | 7716 |
| 20 | 13/16″ | 13.44 | 20.00 | 4300 | 9480 |
| 22 | 7/8" | 16.33 | 24.30 | 5100 | 11244 |
| 24 | 1″ | 19.82 | 29.50 | 6100 | 13448 |
| 28 | 1.1/8″ | 26.41 | 39.30 | 8200 | 18078 |
| 32 | 1.5/16″ | 35.28 | 52.50 | 10700 | 23589 |
Product Details
4 Strand ropes are available from 12 mm dia onwards
Tolerance:
Up to 14 mm = + / – 8% » 16mm & above = + / – 5%
Std Packing:
PE ropes are generally packed individually in plastic bags and then coils are packed in woven bags for shipping.
Coil Lengths:
These ropes are available in 100/220/300 mtrs (Long lengths are available on request.)
Colours:
Yellow, Blue, Green, White, Black. (Other colours are available on request)
- Characteristics:
- Resistance to abrasion
- Shock loading
- Smooth finish
- Easy to handle
- Same breaking strength in dry or wet conditions
- Applications 3 Strand :
- Commercial
- Marine & Fishing
- Domestics
- Trap fishing application
- Packing
- Note:
- The minimum breaking load (MBL) should never be considered as the safe working load of the rope.
- Breaking strength quoted relates to the new dry ropes in soft lay construction. In wet conditions these values may be lower.
